This product has multi-functional control, intelligent control, alarm reminder function and humanized design. Users can flexibly adjust the temperature, accurately required humidity, egg transfer cycle and ventilation cycle incubation management. At the same time, the simple button operation and automatic recording function make it more convenient to use and provide reliable support for incubation work.
Features:
1. Multi-function control: It has multiple functions, such as temperature control, humidity control, automatic egg turning, recording of incubation days, ventilation control and manual lighting to meet different hatching needs.
2. Intelligent control. Functions such as automatic egg turning, automatic recording of incubation days and regular ventilation reduce the user's workload and improve incubation efficiency.
3. Alarm reminder function: When the controller sounds an alarm, just press the button to turn off the buzzer, prompting the user to turn to pay attention and take appropriate measures.
4. Humanized design: Manual lighting function, simple operation and convenient configuration, allowing users to flexibly control and switch lighting equipment without ventilation.
Specification:
Installation type: panel installation
Temperature display range: 0~99℃
Temperature control accuracy: ±0.1℃
Humidity value display range: 0~99
Humidity control accuracy: ±3%RH.
Ambient temperature: -10℃~60℃
Working voltage: 220V 50Hz
Product size: 15.8*8.6*7.8cm
Product weight: 0.75kg
Main features
Number of output channels: 7 channels (overheating, temperature control,
Low temperature, egg turning, right turn, humidity control,
signaling)
Output current: temperature control, cooling ≤8A/AC22PV,
Overheating, egg turning, left turn, right turn, humidity control,
Alarm ≤1A/AC22
Number of egg turnings: 999 times can be recorded.
Turning cycle: 0–999 minutes (factory setting: 90 minutes)
Egg turning time: 0-999 seconds (factory setting 180 seconds)
Ventilation cycle: 0–999 minutes (factory setting: 120 minutes)
Ventilation time: 0-999 seconds (factory setting: 15 seconds)
Measuring line length: about 1.5 meters
packing list:
1*Incubator Controller Icon
Features:
1. Temperature display: displays the internal temperature of the box in real time.
2. Temperature setting: When ℃ is not in the setting state, the set temperature value is displayed. Otherwise displays the number of times the egg has been flipped. This function can be achieved by pressing the mode/page button. Detailed content information
Displayed during status setting, please refer to the instructions for specific settings.
3. Humidity display: Display the humidity in the box in real-time mode.
4. Humidity setting: If the humidity setting is not in the status setting, when the relative humidity % is turned on, the set value humidity value is displayed. Otherwise the number of times to turn the egg is displayed. This function enables "mode/page turning" by pressing a button. Details about what's shown
See specific setup instructions for status setup times.
5. Operation indication: When the machine is powered on, the indicator light lights up, indicating that the machine is already running.
